DESIGNED FOR SPEED – 20 M/S² ACCELERATION – COREXY 20M
How is this speed achieved?
- Ultra lightweight carbon rail
- 40 w ceramic heater
- Powerful 12 w cooling fan
- Welded steel xy chassis
SPAGHETTI FAILURE DETECTION
X1-Carbon integrated AI keeps an eye out for Spaghetti monsters, so you can sleep easy in the knowledge that your printer is safe from this scourge. A spaghetti failure is detected with confidence of 86%.
ADVANCE MATERIAL EMPOWER ADVANCED PROJECTS
Bambu Lab X1 Carbon, equipped with extra cooling and a hardened nozzle and carburized drive gear, unlocks a wider selection of materials, including PA, PC, PET, and TPU, and specializes in carbon fiber and glass fiber reinforced polymers.
MICRO LIDAR ASSISTED BED LEVELING
Bambu Micro Lidar brings micrometer level precision into 3D printing. The system probes the nozzle height, calibrates the flow, and scans the first layer, so the possibilities are endless.
Specifications
Build Volume (W×D×H)
256 × 256 × 256 mm³
Nozzle
0.4 mm Hardened Steel Included (Plus 1x 0.6 mm with Carbon Fiber Bundle)
Hotend
All-Metal
Max Hot End Temperature
300 ℃
Filament Diameter
1.75 mm
Supported Filament
PLA, PETG, TPU, ABS, ASA, PVA, PET Ideal for PA, PC, Carbon/ Glass Fiber Reinforced Polymer
Build Plate Surface
Bambu Cool Plate, Bambu Engineering Plate Included
Max Build Plate Temperature
110℃@220V, 120℃@110V
Max Speed of Tool Head
500 mm/s
Max Acceleration of Tool Head
20 m/s²
Physical Dimensions
389 × 389 × 457 mm³, Package size 480 × 480 × 590 mm³, Net weight 14.13 kg, Gross weight(AMS included) 22.3 kg
Electrical Requirements
100-240 VAC, 50/60 H, 1000W@220V, 350W@110V
